Ports:
24 × Gigabit Ethernet RJ45 ports (10/100/1000 Mbps, Auto Negotiation, Auto MDI/MDIX),4 × Gigabit SFP combo slots,4 × 10G SFP+ uplink ports (2 fixed + 2 optional),1 × Console port (RJ45)

Performance:
Switching Capacity: 128 Gbps,Forwarding Rate: 95.2 Mpps,Packet Buffer: 32 Mb,MAC Address Table: 32,000 entries,Jumbo Frame Support: Up to 12,000 bytes

Layer 3 Features:
Supports Static Routing, RIP v1/v2, OSPF v2, ECMP, VRRP,DHCP Server/Relay/Client, DHCP Snooping,IPv4/IPv6 Routing,ARP Proxy, IGMP & MLD Snooping,Supports up to 4,000 VLANs

Layer 2 Features:
STP/RSTP/MSTP,LACP (Up to 32 LAGs with 8 ports each),Port Mirroring, Loopback Detection,802.1Q VLAN, MAC-based and Protocol-based VLANs,IGMP Snooping v1/v2/v3,Storm Control, Broadcast Control

Security:
802.1X Authentication (Port and MAC-based), RADIUS, Guest VLAN,Access Control Lists (ACLs): Layer 2 to Layer 4,DoS Defense, Dynamic ARP Inspection (DAI),Secure Management via SSL, SSH, SNMPv3

Management:
Web GUI, Command Line Interface (CLI), SNMP v1/v2c/v3,RMON, Syslog, Dual Image Support,Firmware Upgradable via Web or TFTP,Supports Centralized Management via TP-Link Omada Controller

Max Power Consumption: 47W

Removable Power Supply and Cooling Fan

Fan-cooled design for long-term performance

Dimensions: 440 × 330 × 44 mm (1U Rackmountable)

Operating Temp: 0°C to 40°C

Storage Temp: -40°C to 70°C

Humidity: 10–90% (non-condensing)
