Processor:
Supports Intel Xeon E5-1600 v3/v4 and E5-2600 v3/v4 series.
Single or dual CPU configuration.
Up to 36 cores total with dual processors.
Xeon E5-2699 v4 – 22 cores, 2.2 GHz.
Xeon E5-2687W v3 – 10 cores, 3.1 GHz.

Memory:
Up to 256 GB DDR4 ECC Registered memory.
8 DIMM slots total (4 per CPU).
Speeds up to 2400 MHz.

Storage:
Multiple storage configurations supported:
SATA HDD up to 4TB.
SATA SSD up to 4TB.
HP Z Turbo Drive (PCIe SSD) up to 2TB.
RAID support: 0, 1, 5, 10.

Graphics:
Professional GPU support:
NVIDIA Quadro P5000 (16GB GDDR5X).
NVIDIA Quadro M5000 (8GB).
NVIDIA Quadro K2200 (4GB).

Expansion & Ports:
7 expansion slots:
3 × PCIe Gen3 x16.
1 × PCIe Gen3 x8.
1 × PCIe Gen2 x4.
1 × PCIe Gen2 x1.
1 × PCI 32-bit.
Front: 4 × USB 3.0, Audio in/out.
Rear: 4 × USB 3.0, 2 × USB 2.0, Audio, Gigabit LAN.

Power Supply:
Available with 850W or 925W PSU.
