Processor (CPU):
Powered by a high-performance switching ASIC and embedded processor, designed for secure Layer 2/Layer 3 switching with optimized throughput and integration into Fortinet’s Security Fabric.

Memory (RAM):
Equipped with onboard enterprise-grade memory to handle advanced switching features, routing protocols, and security functions (exact RAM specification not publicly disclosed).

Storage:
Built-in flash storage used for firmware, configurations، and system logs. External storage not supported.

Interfaces:
24 × SFP Gigabit fiber ports
4 × SFP+ 10-Gigabit fiber uplink ports
1 × RJ45 console management port
Designed for fiber-centric aggregation and core switching environments

Operating System:
Runs FortiSwitch OS with full FortiLink support for centralized management through FortiGate. Offers comprehensive features such as VLANs, STP, LLDP, link aggregation, 802.1X, DHCP snooping, IGMP snooping, and access control policies.

Performance:
Switching capacity: up to 128 Gbps
Forwarding rate: up to 95.2 Mpps
Ideal for aggregation or distribution layers in fiber-based enterprise networks requiring high throughput and secure integration.

Power Supply:
Equipped with internal AC power supply (100–240V). Optional redundant power supply (RPS) support available depending on deployment needs. No PoE capability.

Cooling System:
Active cooling with variable-speed fans to maintain performance and thermal stability in high-density network environments.

Form Factor:
1U rackmountable metal enclosure with front-facing ports. Suitable for core or aggregation roles in enterprise, campus, or data center networks relying on fiber infrastructure.
