Ports:
24 × RJ-45 autosensing 10/100/1000 Mbps (all support PoE+)

Uplink Ports:
4 × SFP/SFP+ ports supporting 1G/10G fiber connections

PoE Support:
Class 4 PoE (IEEE 802.3at) with a total power budget of 195W

Switching Capacity:
128 Gbps

Forwarding Rate:
95.23 Mpps

Processor:
ARM Cortex-A9 @ 800 MHz

Memory:
512 MB SDRAM, 256 MB flash

Packet Buffer:
1.5 MB

Management: Smart-managed via:
Local web GUI
Aruba Instant On mobile app
Cloud-based portal

Layer Support:
Layer 2+ with basic static Layer 3 routing

Security Features:
IEEE 802.1X authentication, MAC-based access control, VLANs, DoS protection

Quality of Service (QoS):
Traffic prioritization and rate limiting

Energy Efficiency:
Supports IEEE 802.3az Energy Efficient Ethernet

Form Factor:
Rack-mountable (1U height)

Dimensions:
44.25 cm (W) × 26.47 cm (D) × 4.39 cm (H)

Operating Temperature:
0°C to 40°C (32°F to 104°F)

Operating Humidity:
15% to 95% (non-condensing)

Warranty:
Limited Lifetime Warranty from HPE Aruba
